Ceramic Cup Assemblies
1, Flat Ferrite cup
magnets
 |
Part No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
H |
CMcup01-10 |
10 |
4.5 |
2 |
4 |
CMcup01-13 |
13 |
4.5 |
3 |
10 |
CMcup01-16 |
16 |
4.5 |
4.5 |
18 |
CMcup01-20 |
20 |
6 |
10 |
30 |
CMcup01-25 |
25 |
7 |
19 |
40 |
CMcup01-32 |
32 |
7 |
30 |
80 |
CMcup01-36 |
36 |
7.7 |
40 |
100 |
CMcup01-40 |
40 |
8 |
55 |
125 |
CMcup01-47 |
47 |
9 |
80 |
180 |
CMcup01-50 |
50 |
10 |
100 |
220 |
CMcup01-57 |
57 |
10.5 |
140 |
280 |
CMcup01-63 |
63 |
14 |
230 |
350 |
CMcup01-80 |
80 |
18 |
485 |
600 |
CMcup01-100 |
100 |
22 |
900 |
900 |
CMcup01-125 |
125 |
26 |
1680 |
1300 |
|
2, Flat Ferrite cup magnets with hole
 |
Part No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
H |
d1 |
d2 |
CMcup02-13 |
13 |
4.5 |
3.3 |
5 |
3 |
6 |
CMcup02-16 |
16 |
4.5 |
3.3 |
5 |
4 |
14 |
CMcup02-20 |
20 |
6 |
3.3 |
5 |
8 |
26 |
CMcup02-25 |
25 |
7 |
4 |
10 |
15 |
32 |
CMcup02-32 |
32 |
7 |
4 |
10 |
25 |
65 |
CMcup02-36 |
36 |
7.7 |
4 |
10 |
40 |
80 |
CMcup02-40 |
40 |
8 |
5.5 |
12 |
50 |
90 |
CMcup02-47 |
47 |
9 |
5.5 |
10 |
80 |
14 |
CMcup02-50 |
50 |
10 |
5.5 |
18 |
95 |
180 |
CMcup02-57 |
57 |
10.5 |
6.5 |
20 |
125 |
240 |
CMcup02-63 |
63 |
14 |
6.5 |
20 |
200 |
300 |
CMcup02-80A |
80 |
18 |
10.5 |
32 |
480 |
540 |
CMcup02-80B |
81.3 |
11.5 |
9.525 |
32 |
240 |
450 |
CMcup02-83 |
83 |
18 |
10.5 |
34 |
450 |
600 |
CMcup02-100 |
100 |
22 |
10.5 |
32 |
820 |
680 |
|
3, Flat Ferrite cup magnets with threaded hole
 |
Part
No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
H |
M |
K |
CMcup03-25 |
25 |
7 |
4 |
5.2 |
18 |
36 |
CMcup03-32 |
32 |
7 |
4 |
5.2 |
30 |
75 |
CMcup03-40 |
40 |
8 |
4 |
5.2 |
54 |
90 |
CMcup03-50 |
50 |
10 |
6 |
12 |
95 |
170 |
CMcup03-63 |
63 |
14 |
8 |
13 |
210 |
350 |
CMcup03-80A |
80 |
18 |
8 |
14.5 |
470 |
550 |
CMcup03-80B |
80 |
18 |
10 |
14.5 |
470 |
550 |
|
4, Flat Ferrite cup magnets with countersink hole
 |
Part
No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
H |
d1 |
d2 |
CMcup04-16 |
16 |
4.5 |
3.3 |
6.5 |
4 |
14 |
CMcup04-20 |
20 |
6 |
4.2 |
8.6 |
9 |
27 |
CMcup04-25 |
25 |
7 |
5.5 |
10.4 |
16 |
36 |
CMcup04-32 |
32 |
7 |
5.5 |
10.4 |
27 |
72 |
CMcup04-40 |
40 |
8 |
5.5 |
10.4 |
53 |
90 |
|
5, Ferrite cup magnets with thread spigot
 |
Part
No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
h |
H |
d |
CMcup05-10 |
10 |
4.5 |
11.5 |
6 |
3 |
4 |
CMcup05-13 |
13 |
4.5 |
11.5 |
6 |
5 |
10 |
CMcup05-16 |
16 |
4.5 |
11.5 |
6 |
6 |
18 |
CMcup05-20 |
20 |
6 |
13 |
6 |
11 |
30 |
CMcup05-25 |
25 |
7 |
15 |
8 |
22 |
40 |
CMcup05-32 |
32 |
7 |
15 |
8 |
32 |
80 |
CMcup05-36 |
36 |
7.7 |
16 |
8 |
45 |
100 |
CMcup05-40 |
40 |
8 |
18 |
10 |
60 |
125 |
CMcup05-47 |
47 |
9 |
17 |
8 |
90 |
180 |
CMcup05-50 |
50 |
10 |
22 |
12 |
110 |
220 |
CMcup05-57 |
57 |
10.5 |
18.5 |
8 |
145 |
280 |
CMcup05-63 |
63 |
14 |
30 |
15 |
240 |
350 |
CMcup05-80 |
80 |
18 |
34 |
20 |
520 |
600 |
CMcup05-100 |
100 |
22 |
43 |
22 |
940 |
900 |
CMcup05-125 |
125 |
26 |
50 |
25 |
1720 |
1300 |
|
6, Ferrite cup magnets with thread peg
 |
Part
No. |
Dimension(mm) |
Weight
(g) |
Pull
Force
(N) |
D |
h |
H |
M |
CMcup06-10 |
10 |
4.5 |
11.5 |
3 |
3 |
4 |
CMcup06-13 |
13 |
4.5 |
11.5 |
3 |
5 |
10 |
CMcup06-16 |
16 |
4.5 |
11.5 |
3 |
6 |
18 |
CMcup06-20 |
20 |
6 |
13 |
3 |
11 |
30 |
CMcup06-25 |
25 |
7 |
15 |
4 |
22 |
40 |
CMcup06-32 |
32 |
7 |
15 |
4 |
32 |
80 |
CMcup06-47 |
47 |
9 |
17 |
3 |
90 |
180 |
CMcup06-57 |
57 |
10.5 |
18.5 |
4 |
142 |
280 |
CMcup06-63 |
63 |
14 |
29 |
4 |
235 |
350 |
|
|
